150# WSP / 600# WOG
Lead Free Brass body
Chrome plated ball
FNPT x MNPT
Threaded ends (ASME B1.20.1-NPT)
Full port
FKM Double O-Ring Packing
Blow-out proof stem
CSA ½ psi for Natural gas, Propane & LPG service
AB1953, NSF/ANSI 61 & 372 certified
Meet BAA requirement
Lead Free Brass body
Chrome plated ball
FNPT x MNPT
Threaded ends (ASME B1.20.1-NPT)
Full port
FKM Double O-Ring Packing
Blow-out proof stem
CSA ½ psi for Natural gas, Propane & LPG service
AB1953, NSF/ANSI 61 & 372 certified
Meet BAA requirement
Unit of Measure
Specifications
Type |
N/A Ball Valve |
Connection Type |
N/A FNPT x MNPT |
Material |
N/A Lead Free Brass |
Seat Material |
N/A PTFE |
Stem Material |
N/A Lead Free Brass |
Ball Material |
N/A Lead Free Brass / Cr plated |
Size |
N/A 1/4 x 1/8 |
Operating Pressure [Max] |
N/A 600 psi |
Operating Temperature [Min] |
N/A 15 ºF |
Operating Temperature [Max] |
N/A 160 ºF |
Cv Coefficient |
N/A 2.88 |
Valve Operator |
N/A Lever Handle |
Valve Operator Material |
N/A Steel / Geomet® plated |
Weight |
N/A 0.162 lb |
